The Staffa HPC Series is a high power dual displacement radial piston motor, an enhanced version of the HMC Series with special low-friction components combined with crankcase flushing flow to achieve increased shaft power.
The range consists of 7 frame sizes ranging from the HPC080 (1,344cc/rev) to HPC325 (5326cc/rev).
Kawasaki Staffa high torque, low speed radial piston motors use hydrostatic balancing techniques to achieve high efficiency, combined with good breakout torque and smooth running capability.
The HPC series dual displacement models have two pre-set displacements which can be chosen from a wide range to suit specific application requirements. The displacements are hydraulically selected by a directional control valve which can be remote mounted or directly on the motor. Motor displacement can be changed with ease when the motor is running.
These motors are also available in a continuously variable version using either hydro-mechanical or electro-hydraulic control methods. Other mounting options are available on request to
match many of the competitor interfaces.
