The SS Series of push/pull manual diverter valves are made by Prince in the USA.
This 3-way 2 position selector valve will allow one pump source to supply two circuits. With the standard selector spool, pulling the spool out diverts oil to the nearest handle. Pushing the spool in diverts oil to the port nearest the handle. The valve has an inlet on both the bottom and front of the valve body.
Special options include a lever handle and a float spool. The float spool connects the inlet to both outlets when the spool is pushed in and blocks both outlets when the spool is pulled out.
- Maximum inlet flow 75 L/min
- Maximum pressure 170 bar
